Multiaxial Fabrics
Direct roving is arranged as one-way parallel in direction of 0°,90°.+45°and -45°(could be one or any of the four directions), then stitch the roving with coils into Unidirectional, Biaxial or Multiaxial fabrics. Applied in process of FRP pultrusion, RTM,
1. Description
Direct roving is arranged as one-way parallel in direction of 0°,90°.+45°and -45°(could be one or any of the four directions), then stitch the roving with coils into Unidirectional, Biaxial or Multiaxial fabrics. Applying in process of FRP pultrusion, RTM, etc., suitable to be used in production of ship, wind energy, environment protection equipment, etc.
2. Properties & Advantages
* High mechanical strength on mufti-directions, can be freely designed as per requirements.
* Multi layer structure simplifies the forming process, improve production efficiency.
* Rapid wet-out, good fitting performance in mould, easily bubbles out.
3. Technical Data
|
Specs, g/m2 (directions) |
Width, mm |
Compatible Resins |
|
EMK430(90) |
≤2540 |
UP VE EP |
|
EMK1200(0,90) |
≤2540 |
UP VE EP |
|
EMK450/800(0,90) |
≤2540 |
UP VE EP |
|
EMK1200(0, ± 45) |
≤2540 |
UP VE EP |
|
EMK1200(0, ±45,90) |
≤2540 |
UP VE EP |
|
EMK275/800(0，, 45,90) |
≤2540 |
UP VE EP |
4. Packing
As per clients’ request, this product can be cut into various width in the course of production. Winding on the cardboard tube with outside diameter of 76mm, then each roll is put into a Polythene bag before packed with a cardboard box.
Can be packed and shipped as per customers’ request.
5. Storage
Unless otherwise required, the products should be stored in dry and cool place, Please keep the products in its original package before using to prevent moisture.
6. Application Examples
